H Series BWRO membrane elements delivering differentiated value in drinking and wastewater treatment
Veolia H Series BWRO membrane elements have been designed to address the growing market focus on high quality permeates, system cost of ownership and water reuse policies and regulations that have resulted in more challenging RO feeds.
High Rejection Performance:
- Tighter rejection range for all elements in the series delivers highest quality permeate for critical applications.
- Results in longer life, less maintenance, and lower operating costs for downstream equipment, such as EDI, resin, or high-pressure boilers.
Low Energy Performance:
- Low energy/high rejection elements (AK H & AG LE H) provide a solution for balancing the need for low permeate TDS and the need to reduce energy consumption.
- Optimizes 2nd pass RO to achieve lowest TDS in the permeate and lowest costs associated with energy consumption.
Fouling Resistant Performance:
- Fouling resistant elements that maintain rejection and pressure performance in the presence of high TDS and high BOD/COD.
- Results in long lasting element with sustained performance in challenging applications.
Performance priority
for end-user |
Common Applications |
Model Name / SKU # |
Flow (GPD) |
Typical Rejection |
Min. Rejection |
Veolia Fact Sheet |
| Highest rejection of salts |
High pressure boiler feed,
High purity water |
Element,AG-400 H / 3150329 |
11,000 |
99.8 |
99.65 |
AG H Series |
| Highest rejection of salts |
High pressure boiler feed,
High purity water |
Element,AG-440 H / 3150328 |
12,000 |
99.8 |
99.65 |
AG H Series |
| Low energy consumption |
2nd pass RO, Drinking water |
Element,AK-400 H / 3150326 |
11,000 |
99.65 |
99.5 |
AK H Series |
| Low energy consumption |
2nd pass RO, Drinking water |
Element,AK-440 H / 3150327 |
12,000 |
99.65 |
99.5 |
AK H Series |
| Low energy consumption |
Drinking water |
Element,AG-400 LE H / 3187569 |
10,000 |
99.5 |
99.0 |
AG LE H Series |
| Low energy consumption |
Drinking water |
Element,AG-440 LE H / 3187650 |
11,000 |
99.5 |
99.0 |
AG LE H Series |
Fouling resistance to
challenging feed water |
Wastewater applications
requiring high TDS removal |
Element AG-400 FR H / 3187651 |
11,000 |
99.8 |
99.5 |
AG FR H Series |
Drinking Water Reverse Osmosis Elements Brochure
Veolia product portfolio includes various membranes and elements which are well suited for all types of drinking water applications
Wastewater Reverse Osmosis Elements Brochure
Veolia has spiral wound reverse osmosis membranes to handle all types of wastewater applications
