Conductivity and Lean Lab with Sievers TOC

Streamline your compendia testing with Sievers Lean Lab

Using a single sample vial, the Sievers M9 can simultaneously analyze and report two discrete results for TOC and conductivity for compliance with USP <643> and <645>. Compared to manual conductivity testing, using the Sievers M9 can save time, eliminate sample-handling issues, enhance data integrity, and minimize potential failures.

Experience the power of combined conductivity and TOC for cleaning

Both TOC and conductivity are well-suited analytical methods for cleaning validation. Using Sievers Analyzers, you can measure TOC and conductivity simultaneously and cover virtually all potential contaminants and compounds that may be present- whether organic or inorganic. Plus, you'll have even more powerful data analytics.

Portfolio
Products
Resources
DUCT Vials

Portfolio

Sievers TOC Analyzers for conductivity

In addition to quantitative testing of TOC for compliance with USP <643>, the M9 Analyzer has an option for simultaneous Stage 1 conductivity testing for compliance with USP <645>. The automation of this technology makes compliance testing fast, efficient, and reliable using the M9 conductivity cell, which meets or exceeds all instrument specifications set forth in USP <645>. The M9 measures non-temperature compensated sample conductivity and temperature, and it provides the necessary acceptance criteria tables for USP, EP, CP, and IP.

The Sievers 500 RL meets all USP <645> Stage 1 regulatory monitoring requirements, reporting raw conductivity, temperature, and temperature compensated conductivity. Procedures compliant with USP <645> enable temperature accuracy verification.

The 500 RL also supports conductivity testing in accordance with JP <2.51>.

Products

Conductivity products

Sievers M9 Laboratory TOC Analyzer

Maximize productivity without sacrificing accuracy or ease-of-use

Sievers M9 Portable TOC Analyzer

Greater versatility of sampling modes and applications

Sievers 500 RL On-Line TOC Analyzer

Reliable, accurate performance for online TOC monitoring and real-time testing

Sievers TOC Standards and Sample Vials

Minimize risks and eliminate variables with Sievers certified vials and standards

Resources

Conductivity Resources

Recorded Webinars

DUCT Vials

How to get the most out of your measurements

Performing simultaneous Stage 1 conductivity and TOC from the same vessel requires that the vessel not contribute in any significant way to either conductivity or TOC. Sievers Dual Use Conductivity and TOC (DUCT) vials are designed to minimize both ionic and organic contamination with the Sievers M9 to automate the testing for compliance with <643> and <645>.

Sievers DUCT vials have a proprietary coating to eliminate conductivity contributions from the vial surfaces and specialty caps to minimize the diffusion of CO2 into the sample during storage. These vials are proven to not only be suitable for conductivity and TOC testing, but superior to many of the established vessels used today.

Dual Use Conductivity and TOC (DUCT) Vials (300 00288)
Sievers Total Traceability: Certified Reference Materials & Vials for TOC Analysis (300 00259)

Conductivity Bridge Study: From Benchtop Meter and Probe to Automated Sievers M9

This application note provides a road map for how to perform a bridge study between the current state of offline Stage 1 conductivity testing with a benchtop meter and probe to the desired future state of automated, Stage 1 conductivity testing with the Sievers M9 TOC Analyzer with Conductivity.

Download (PDF)

Sievers M9: M-Power Your Lab for Lean Efficiencies

TOC and conductivity are critical attributes for compendia assurance of water quality that are traditionally tested separately in the lab and can be labor and time intensive. The Sievers M9 offers simultaneous measurement of TOC and conductivity in a single vial to save you time and resources.

Download (PDF)

Improved Efficiency and Lower Costs Using Simultaneous Testing for TOC and Conductivity

To improve efficiency and lower costs, a Global Biotechnology Company chose to evaluate Veolia’s Analytical Instruments Sievers M9 Laboratory Analyzer. an instrument which simultaneously measures TOC and USP Stage 1 Conductivity from a single container, a Dual Use Conductivity and TOC (DUCT) vial.

Download (PDF)
